- Selectable operating mode (normal mode, time switch mode, flashing mode)
- Selectable relay mode (NC/NO)
- Variable On and Off delay times
- Two selectable logic operations (AND, OR, NAND, NOR, XOR, FILTER, TRIGGER)
- Selectable sending of status objects on request, cyclically and/or automatically after a change
- Selectable switching state on bus voltage failure
- Selectable start value of the switching object on bus voltage recovery
- Optional addition of a night mode object for time-limited switching On of the output, i.e. the illumination, at night
- Variable On period at night or time switch mode
- Selectable addition of an object to change the On period at night or time switch mode
- Selectable post-triggering (1x, 2x, 3x, 4x, 5x) of the On period in time switch mode
- Selectable warning signal prior to imminent switching-off by brief off and on switching (flashing) at night or in time switch mode and/or via an optional warning object
Per output selectable functions:
- For manual override ON
- For permanent OFF switching
- Blocking of the output
- For switching on or off in forced mode
- Counting of operating hours and threshold monitoring
- Counting of load cycles and threshold monitoring
- Integrated 8-bit scene control with up to 8 scenes per output
- Construction site function switching
- Object for monitoring of device function
- Object for targeted retrieval of status values
